TudorandClaude Opus 5 3f0e05cc99 feat(home): use the supplied hero artwork instead of a drawn one ...

Replaces the hand-drawn SVG landscape with the illustration supplied by the
project owner. Master is assets/hero-source.png; everything under
public/brand/hero-* comes from scripts/build-hero-images.js and should never be
hand-edited.

LAYOUT

The artwork is composed as a full-bleed hero: it reserves an empty cream area
down its left side for the headline. The old hero was a two-column grid with
art in the right 0.88fr, which would have cropped that reserved area off and
shrunk the scene into a thumbnail — the one thing the picture is built not to
be. So the panel is now a single layered block: artwork behind, copy on top,
and below the one-column breakpoint the artwork leaves the background and
becomes a band under the search.

Overlaying does not survive down to phone widths — the panel gets too narrow
for the copy to stay inside the cream, so the scrim would have to cover nearly
the whole image and you would be left with a tinted rectangle. Hence the
switch at 860px rather than a single treatment stretched across every width.

CONTRAST

The copy sits on a gradient of --hero-ground, a new token sampled from the
artwork's own cream (#FDF9F3) rather than from Sand. Sand is eight to thirteen
points darker per channel, which leaves a visible seam straight down the hero.
The scrim exists because the artwork is a fixed image on a fluid panel: past
some width the headline would otherwise land on hillside green.

Measured on rendered pixels, sampling background up to 120px beyond the right
edge of each line, so a longer line still has margin:

  light  title 14.36:1   body 6.52:1
  dark   title 11.01:1   body 6.44:1

The worst light case is hillside green showing through the scrim at 6.52:1.

TWO CROPS

The slot is two shapes: roughly 2.1:1–2.7:1 behind the desktop panel, and
2.6:1–4.9:1 as the band. A single file under object-fit: cover centre-crops,
and at the band's extreme that slices a strip through the scene and loses the
schoolhouse — exactly how the drawn hero failed on phones. <picture> switches
crop, not just resolution: the band file is pre-cropped around the school and
is already near 2.6:1, with the subject at ~65% across so squeezing toward
4.9:1 crops the empty sides instead.

WEIGHT

1.6 MB PNG in, AVIF and WebP out; a browser fetches exactly one file — about
23–33 kB on desktop, 9–18 kB on a phone. The JPEG is only the <img> fallback.
`sizes` describes the real panel box (max-width 1400 minus padding) rather than
100vw, which over-requested a candidate at every width on the LCP element.

DARK THEME

A raster cannot be re-graded token by token the way the drawing was, but it
would reproduce the same failure — a bright illustration is the brightest
object on a near-black page. It is dimmed in CSS to read as dusk, and the
scrim fades it into the dark panel rather than into cream.

TESTS

The two illustration journeys are replaced by three, each covering a failure
that still renders a valid-looking page: the artwork actually loading
(naturalWidth, not src), the crop switching at the breakpoint, a modern format
winning negotiation, and the dark theme dimming it.

public/brand/CREDITS.md records provenance for every asset in that folder. The
hero's licence line is marked unconfirmed — that one needs the owner.

Co-Authored-By: Claude Opus 5 <noreply@anthropic.com>
